| Basic Information | |||
| Usage | Vehicle for Special Work | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 8995mm | ||
| Width | 2500mm | ||
| Height | 3900mm | ||
| Curb Weight | 11800kg | ||
| Gross Weight | 13400kg | ||
| Seats | 1 | ||
| Max Speed | 100km/h | ||
| Chassis | |||
| Chassis Model | ZK6906H5Y | ||
| Front/Rear Overhang | 1915/2780mm | ||
| Number of Leaf Springs | 8/9 | ||
| Number of Axles | 2 | ||
| Wheelbase | 4300mm | ||
| Axle Load | 4100/9300kg | ||
| Front Wheel Track | 2035,2075,2095mm | ||
| Rear Wheel Track | 1860,1880mm | ||
| Approaching/Departuring Angle | 10/8° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 10R22.5,275/70R22.5,275/80R22.5 | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| WP6.245E50 | Weichai (Weifang) Medium Engine Co., Ltd. | 180kW | 6750ml |
| YC6J245-58 | Guangxi Yuchai Machinery Co., Ltd. | 180kW | 6500ml |
| YC6A270-50 | Guangxi Yuchai Machinery Co., Ltd. | 199kW | 7520ml |
| YC6J245-52 | Guangxi Yuchai Machinery Co., Ltd. | 180kW | 6494ml |
| WP7.270E53 | Weichai Power Co., Ltd. | 199kW | 7470ml |
