| Basic Information | |||
| Usage | Vehicle for Special Work | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 11990mm | ||
| Width | 2520mm | ||
| Height | 3980mm | ||
| Curb Weight | 20205kg | ||
| Gross Weight | 20400kg | ||
| Seats | 2,3 | ||
| Max Speed | 110km/h | ||
| Chassis | |||
| Chassis Model | ZZ1266N504GE1 | ||
| Front/Rear Overhang | 1430/3185mm | ||
| Number of Leaf Springs | 3/-/- | ||
| Number of Axles | 3 | ||
| Wheelbase | 3875+1400,4275+1400,4575+1400,4975+1400,5775+1400,5175+1400,5975+1400mm | ||
| Axle Load | 5500/14900(two axles)kg | ||
| Front Wheel Track | 1995,2014mm | ||
| Rear Wheel Track | 1844/1844mm | ||
| Approaching/Departuring Angle | 16/10° | ||
| Tire | |||
| Number of Tires | 10 | ||
| Tire | 11.00R20 18PR,295/80R22.5 18PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| MC07.28-50 | China National Heavy Duty Truck Group Co., Ltd. | 206kW | 6870ml |
| MC07.31-50 | China National Heavy Duty Truck Group Co., Ltd. | 228kW | 6870ml |
| MC07.34-50 | China National Heavy Duty Truck Group Co., Ltd. | 248kW | 6870ml |
| MC07.28-52 | China National Heavy Duty Truck Group Co., Ltd. | 206kW | 6870ml |
| MC07.31-52 | China National Heavy Duty Truck Group Co., Ltd. | 228kW | 6870ml |
| MC07.34-52 | China National Heavy Duty Truck Group Co., Ltd. | 248kW | 6870ml |
