| Basic Information | |||
| Usage | Vehicle for Special Work | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 8125mm | ||
| Width | 2480mm | ||
| Height | 3890mm | ||
| Curb Weight | 9600kg | ||
| Gross Weight | 11000kg | ||
| Seats | 1 | ||
| Max Speed | 100km/h | ||
| Chassis | |||
| Chassis Model | XMQ6802AYD5D | ||
| Front/Rear Overhang | 1775/2500mm | ||
| Number of Leaf Springs | 6/9,3/4,7/10,4/5,7/11,-/- | ||
| Number of Axles | 2 | ||
| Wheelbase | 3850mm | ||
| Axle Load | 3800/7200kg | ||
| Front Wheel Track | 2066,2030,2087mm | ||
| Rear Wheel Track | 1802,1842,1860mm | ||
| Approaching/Departuring Angle | 10/8° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 8R22.5,255/70R22.5 | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| YC4G200-50 | Guangxi Yuchai Machinery Co., Ltd. | 147kW | 5200ml |
| WP5.200E51 | Weichai Power Co., Ltd. | 147kW | 4980ml |
