| Basic Information | |||
| Usage | Vehicle for Special Work | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 11950mm | ||
| Width | 2510mm | ||
| Height | 3980mm | ||
| Curb Weight | 18370kg | ||
| Gross Weight | 18500kg | ||
| Seats | 2 | ||
| Max Speed | 110km/h | ||
| Chassis | |||
| Chassis Model | FH420 64R B | ||
| Front/Rear Overhang | 1365/3215mm | ||
| Number of Leaf Springs | 2/-/- | ||
| Number of Axles | 3 | ||
| Wheelbase | 6000+1370mm | ||
| Axle Load | 6000/12500(two axles)kg | ||
| Front Wheel Track | 2035mm | ||
| Rear Wheel Track | 1834/1834mm | ||
| Approaching/Departuring Angle | 15/12° | ||
| Tire | |||
| Number of Tires | 10 | ||
| Tire | 295/80 R22.5 | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| D13C420S EUV | Volvo Power System Co., Ltd. | 310kW | 12777ml |
