| Basic Information | |||
| Usage | Police Van | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 5143,4963,5443,5263,5263,5563mm | ||
| Width | 2000mm | ||
| Height | 2195,2398,2095,2150,2380,2070mm | ||
| Curb Weight | 2480kg | ||
| Gross Weight | 3550kg | ||
| Seats | 3+3,3+2,2+3 | ||
| Max Speed | 140km/h | ||
| Chassis | |||
| Chassis Model | JX5040XXYTDA-L5 | ||
| Front/Rear Overhang | 1113/1097,933/1097,1113/1397,933/1397,1113/1217,1113/1517mm | ||
| Number of Leaf Springs | -/2 | ||
| Number of Axles | 2 | ||
| Wheelbase | 2933mm | ||
| Axle Load | 1550/2000kg | ||
| Front Wheel Track | 1745mm | ||
| Rear Wheel Track | 1700mm | ||
| Approaching/Departuring Angle | 20/23,20/21,22/25,22/23° | ||
| Tire | |||
| Number of Tires | 4 | ||
| Tire | 215/75R16LT | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| DURATORQ4D225H | Jiangling Motors Corporation Ltd. | 100kW | 2198ml |
