| Basic Information | |||
| Usage | Police Van | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB3847-2005,GB17691-2018 national Ⅵ emission standards | ||
| Length | 5571,5341,5481,5431mm | ||
| Width | 2032mm | ||
| Height | 2425,2080,2460,2110,2370,2020mm | ||
| Curb Weight | 2590kg | ||
| Gross Weight | 3510kg | ||
| Seats | 6,5 | ||
| Max Speed | 156km/h | ||
| Chassis | |||
| Chassis Model | JX6533TB-M6 | ||
| Front/Rear Overhang | 1154/1117,1014/1027,1154/1027,1014/1117mm | ||
| Number of Leaf Springs | -/1,-/2 | ||
| Number of Axles | 2 | ||
| Wheelbase | 3300mm | ||
| Axle Load | 1570/1940kg | ||
| Front Wheel Track | 1736mm | ||
| Rear Wheel Track | 1720mm | ||
| Approaching/Departuring Angle | 18/23,20/25,18/25,20/23° | ||
| Tire | |||
| Number of Tires | 4 | ||
| Tire | 215/75R16LT 10PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| DURATORQ4D206H | Jiangling Motor Corporation Ltd. | 90kW | 1998ml |
