| Basic Information | |||
| Usage | Police Van | ||
| Fuel Type | Gasoline | ||
| Emission Standard | GB18352.5-2013 national Ⅴ emission standards | ||
| Length | 4976,5336,4666,5026,4796,5156,4846,5206mm | ||
| Width | 1974mm | ||
| Height | 2080,2280,2040,2240,1990mm | ||
| Curb Weight | 2220kg | ||
| Gross Weight | 2830kg | ||
| Seats | 6,5 | ||
| Max Speed | 140km/h | ||
| Chassis | |||
| Chassis Model | JX6470PA-L5 | ||
| Front/Rear Overhang | 1075/1066,1075/1426,945/886,945/1246,1075/886,1075/1246,945/1066,945/1426mm | ||
| Number of Leaf Springs | -/3 | ||
| Number of Axles | 2 | ||
| Wheelbase | 2835mm | ||
| Axle Load | 1220/1610kg | ||
| Front Wheel Track | 1692mm | ||
| Rear Wheel Track | 1700mm | ||
| Approaching/Departuring Angle | 17/16,17/15,19/18,19/17,17/18,17/17,19/16,19/15° | ||
| Tire | |||
| Number of Tires | 4 | ||
| Tire | 215/70R15LT | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| 4G69S4N | Shenyang Aerospace Sanling Automobile Engine Manufacture Co., Ltd. | 100kW | 2378ml |
