| Basic Information | |||
| Usage | Others | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 10110mm | ||
| Width | 2500mm | ||
| Height | 3890mm | ||
| Curb Weight | 14600kg | ||
| Gross Weight | 16000kg | ||
| Seats | 3,2 | ||
| Max Speed | 110km/h | ||
| Chassis | |||
| Chassis Model | ZZ5166XXYM561GE1 | ||
| Front/Rear Overhang | 1430/3080mm | ||
| Number of Leaf Springs | 3/3+2,3/9+8,11/9+8,3/2+2 | ||
| Number of Axles | 2 | ||
| Wheelbase | 5600mm | ||
| Axle Load | 6000/10000kg | ||
| Front Wheel Track | 1923,1998mm | ||
| Rear Wheel Track | 1764,1844mm | ||
| Approaching/Departuring Angle | 16/10° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 10.00R20,11.00R20,11R22.5,275/80R22.5,295/80R22.5 | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| MC07.21-50 | China National Heavy Duty Truck Group Co., Ltd. | 151kW | 6870ml |
| MC07.24-50 | China National Heavy Duty Truck Group Co., Ltd. | 176kW | 6870ml |
| MC07.28-50 | China National Heavy Duty Truck Group Co., Ltd. | 206kW | 6870ml |
| MC05.21-50 | China National Heavy Duty Truck Group Co., Ltd. | 151kW | 4580ml |
