| Basic Information | |||
| Usage | Vehicle for Special Work | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 11990mm | ||
| Width | 2520mm | ||
| Height | 3980mm | ||
| Curb Weight | 20270kg | ||
| Gross Weight | 20400kg | ||
| Seats | 2 | ||
| Max Speed | 104km/h | ||
| Chassis | |||
| Chassis Model | ZZ1266V504HE1K | ||
| Front/Rear Overhang | 1475/3115mm | ||
| Number of Leaf Springs | -/- | ||
| Number of Axles | 3 | ||
| Wheelbase | 5000+1400,5200+1400,5800+1400,6000+1400mm | ||
| Axle Load | 5500/14900(two axles)kg | ||
| Front Wheel Track | 2022,2041mm | ||
| Rear Wheel Track | 1830/1830mm | ||
| Approaching/Departuring Angle | 19/12° | ||
| Tire | |||
| Number of Tires | 10 | ||
| Tire | 295/80R22.5,12R22.5,12.00R20 16PR,11.00R20 | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| MC11.36-50 | China National Heavy Duty Truck Group Co., Ltd. | 268kW | 10518ml |
| MC11.40-50 | China National Heavy Duty Truck Group Co., Ltd. | 297kW | 10518ml |
| MC11.44-50 | China National Heavy Duty Truck Group Co., Ltd. | 327kW | 10518ml |
| MC13.48-50 | China National Heavy Duty Truck Group Co., Ltd. | 356kW | 12419ml |
| MC13.54-50 | China National Heavy Duty Truck Group Co., Ltd. | 400kW | 12419ml |
