| Basic Information | |||
| Usage | Vehicle for Special Work | ||
| Fuel Type | Gasoline | ||
| Emission Standard | GB18352.5-2013 national Ⅴ emission standards | ||
| Length | 5039mm | ||
| Width | 1989mm | ||
| Height | 2130mm | ||
| Curb Weight | 2350kg | ||
| Gross Weight | 2685kg | ||
| Seats | 2-5 | ||
| Max Speed | 225km/h | ||
| Chassis | |||
| Chassis Model | SVW6505JHD | ||
| Front/Rear Overhang | 900/1159mm | ||
| Number of Leaf Springs | -/- | ||
| Number of Axles | 2 | ||
| Wheelbase | 2980mm | ||
| Axle Load | 1330/1355kg | ||
| Front Wheel Track | 1704mm | ||
| Rear Wheel Track | 1721mm | ||
| Approaching/Departuring Angle | 20/17° | ||
| Tire | |||
| Number of Tires | 4 | ||
| Tire | 245/60 R18 105V,255/55 R19 107V,255/50 R20 109V | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| DDK | Salzgitter | 220kW | 2492ml |
