| Basic Information | |||
| Usage | Refuse Collector | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB3847-2005,GB17691-2018 national Ⅵ emission standards | ||
| Length | 5830mm | ||
| Width | 2100mm | ||
| Height | 2750mm | ||
| Curb Weight | 4650kg | ||
| Gross Weight | 7495kg | ||
| Seats | 3 | ||
| Max Speed | 100km/h | ||
| Chassis | |||
| Chassis Model | JX1073TG26 | ||
| Front/Rear Overhang | 1125/1345mm | ||
| Number of Leaf Springs | 8/7+7,8/8+8 | ||
| Number of Axles | 2 | ||
| Wheelbase | 3360mm | ||
| Axle Load | 2665/4830kg | ||
| Front Wheel Track | 1580mm | ||
| Rear Wheel Track | 1530mm | ||
| Approaching/Departuring Angle | 20/18° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 7.50R16LT 14PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| JX4D306H | Jiangling Motors Corporation Ltd. | 112kW | 2892ml |
