| Basic Information | |||
| Usage | Aluminum Alloy Oil Tanker | ||
| Fuel Type | Natural gas | ||
| Emission Standard | GB11340-2005,GB18285-2005,GB17691-2005 national Ⅴ emission standards | ||
| Length | 9150,8305mm | ||
| Width | 2500mm | ||
| Height | 3040mm | ||
| Curb Weight | 8960kg | ||
| Gross Weight | 16000kg | ||
| Seats | 3 | ||
| Max Speed | 90km/h | ||
| Chassis | |||
| Chassis Model | EQ1160GD5NJ | ||
| Front/Rear Overhang | 2275/2375,1430/2375mm | ||
| Number of Leaf Springs | 8/10+8,9/11+8 | ||
| Number of Axles | 2 | ||
| Wheelbase | 4500,4950,5100,5200,5600,3800mm | ||
| Axle Load | 6000/10000kg | ||
| Front Wheel Track | 1876mm | ||
| Rear Wheel Track | 1860mm | ||
| Approaching/Departuring Angle | 13/11,18/11° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 10.00-20 16PR,10.00R20 16PR,295/80R22.5 18PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| YC6J190N-52 | Guangxi Yuchai Machinery Co., Ltd. | 140kW | 6494ml |
| YC6J210N-52 | Guangxi Yuchai Machinery Co., Ltd. | 155kW | 6494ml |
| YC6G230N-50 | Guangxi Yuchai Machinery Co., Ltd. | 170kW | 7800ml |
| NQ200CN5 | Dongfeng Nanchong Automobile Co., Ltd. | 147kW | 4750ml |
| B6.7GE5 190 | Hubei Hanyu Power Technology Co., Ltd. | 140kW | 6700ml |
| B6.7GE5 210 | Hubei Hanyu Power Technology Co., Ltd. | 155kW | 6700ml |
