| Basic Information | |||
| Usage | Vacuum Sweeper | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 6695mm | ||
| Width | 2240mm | ||
| Height | 2670mm | ||
| Curb Weight | 7730kg | ||
| Gross Weight | 9990kg | ||
| Seats | 3 | ||
| Max Speed | 95km/h | ||
| Chassis | |||
| Chassis Model | ZZ1107G421CE199 | ||
| Front/Rear Overhang | 1160/1735mm | ||
| Number of Leaf Springs | 8/9+6,11/9+7,11/11+7,9/12+9,3/3+2 | ||
| Number of Axles | 2 | ||
| Wheelbase | 3800,4200mm | ||
| Axle Load | 3590/6400kg | ||
| Front Wheel Track | 1585,1780,1825mm | ||
| Rear Wheel Track | 1605,1796mm | ||
| Approaching/Departuring Angle | 18/18° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 8.25R16LT,8.25R20 14PR,9R17.5,9R22.5 | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| ISF3.8s5154 | Beijing Foton Cummins Engine Co., Ltd. | 115kW | 3760ml |
| ISF3.8s5168 | Beijing Foton Cummins Engine Co., Ltd. | 125kW | 3760ml |
| MC05.14-50 | China National Heavy Duty Truck Group Co., Ltd. | 103kW | 4580ml |
| MC05.16-50 | China National Heavy Duty Truck Group Co., Ltd. | 118kW | 4580ml |
| MC05.18-50 | China National Heavy Duty Truck Group Co., Ltd. | 132kW | 4580ml |
| CY4SK151 | Dongfeng Chaoyang Diesel Co., Ltd. | 125kW | 3856ml |
| MC04.16-50 | China National Heavy Duty Truck Group Co., Ltd. | 115kW | 3760ml |
| MC04.17-50 | China National Heavy Duty Truck Group Co., Ltd. | 125kW | 3760ml |
| YNF40E1 | Kunming Yunnei Power Co., Ltd. | 125kW | 3920ml |
