| Basic Information | |||
| Usage | Vehicle for Special Work | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB3847-2005,GB17691-2005 national V emission standards | ||
| Length | 7860mm | ||
| Width | 2510mm | ||
| Height | 3480mm | ||
| Curb Weight | 11105kg | ||
| Gross Weight | 11300kg | ||
| Seats | 3 | ||
| Max Speed | 98km/h | ||
| Chassis | |||
| Chassis Model | DFL1120B21 | ||
| Front/Rear Overhang | 1440/1920mm | ||
| Number of Leaf Springs | 8/10+8,7/9+6 | ||
| Number of Axles | 2 | ||
| Wheelbase | 3650,3800,4200,4500,4700,5000mm | ||
| Axle Load | 4000/7300kg | ||
| Front Wheel Track | 1880,1900mm | ||
| Rear Wheel Track | 1860,1800,1820mm | ||
| Approaching/Departuring Angle | 20/18° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 9.00-20 14PR,9.00-20 16PR,9.00R20 14PR,9.00R20 16PR,275/70R22.5,255/70R22.5 | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| ISD180 50 | Dongfeng Cummins Engine Co., Ltd. | 132kW | 4500ml |
| ISD160 50 | Dongfeng Cummins Engine Co., Ltd. | 118kW | 4500ml |
| ISB180 50 | Dongfeng Cummins Engine Co., Ltd. | 132kW | 5900ml |
| EQH180-53 | Dongfeng Trucks Co., Ltd. | 132kW | 4752ml |
| EQH160-53 | Dongfeng Trucks Co., Ltd. | 118kW | 4752ml |
