| Basic Information | |||
| Usage | Recreational Vehicle | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 9355mm | ||
| Width | 2532mm | ||
| Height | 3777mm | ||
| Curb Weight | 13146kg | ||
| Gross Weight | 13350kg | ||
| Seats | 3 | ||
| Max Speed | 98km/h | ||
| Chassis | |||
| Chassis Model | DFH1180BX1JV | ||
| Front/Rear Overhang | 1430/2925mm | ||
| Number of Leaf Springs | 11/11+10,8/10+8,3/4+3,2/3+2 | ||
| Number of Axles | 2 | ||
| Wheelbase | 4700,5000,4500mm | ||
| Axle Load | 4670/8680kg | ||
| Front Wheel Track | 1815,1855,1900mm | ||
| Rear Wheel Track | 1800mm | ||
| Approaching/Departuring Angle | 20/10° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 295/80R22.5,10.00R20 18PR,12R22.5 16PR, 12R22.5 18PR,295/60R22.5 18PR,11R22.5 18PR,275/80R22.5 18PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| EQH160-52 | Dongfeng Trucks Co., Ltd. | 118kW | 4752ml |
| EQH160-53 | Dongfeng Trucks Co., Ltd. | 118kW | 4752ml |
| EQH180-52 | Dongfeng Trucks Co., Ltd. | 132kW | 4752ml |
| EQH180-53 | Dongfeng Trucks Co., Ltd. | 132kW | 4752ml |
