| Basic Information | |||
| Usage | Recreational Vehicle | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards,G B3847-2005 | ||
| Length | 5960,5940,5980mm | ||
| Width | 2260,2200,2300,2385mm | ||
| Height | 3075,2955,3010mm | ||
| Curb Weight | 4000kg | ||
| Gross Weight | 4498kg | ||
| Seats | 4-6 | ||
| Max Speed | 160km/h | ||
| Chassis | |||
| Chassis Model | 45C17H | ||
| Front/Rear Overhang | 1008/1502,1008/1482,1008/1522mm | ||
| Number of Leaf Springs | -/- | ||
| Number of Axles | 2 | ||
| Wheelbase | 3450mm | ||
| Axle Load | 1600/2898kg | ||
| Front Wheel Track | 1724mm | ||
| Rear Wheel Track | 1542mm | ||
| Approaching/Departuring Angle | 21/11° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 195/75R16C | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| F1CFL411F*A | FPT INDUSTRIAL S.p.A. | 126kW | 2998ml |
