| Basic Information | |||
| Usage | Road-block Removal Truck | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB3847-2005,GB17691-2005 national Ⅳ emission standards | ||
| Length | 9125,9425mm | ||
| Width | 2400mm | ||
| Height | 2620mm | ||
| Curb Weight | 7236kg | ||
| Gross Weight | 12490kg | ||
| Seats | 3 | ||
| Max Speed | 98km/h | ||
| Chassis | |||
| Chassis Model | DFL1120B18 | ||
| Front/Rear Overhang | 1430/2760mm | ||
| Number of Leaf Springs | 11/11+10 | ||
| Number of Axles | 2 | ||
| Wheelbase | 4700,5000mm | ||
| Axle Load | 4400/8090kg | ||
| Front Wheel Track | 1815mm | ||
| Rear Wheel Track | 1800mm | ||
| Approaching/Departuring Angle | 20/10° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 8.25-20,8.25R20,9.00-20,9.00R20,255/70R22.5 | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| EQH160-40 | Dongfeng Trucks Co., Ltd. | ||
| EQH180-40 | Dongfeng Trucks Co., Ltd. | ||
