| Basic Information | |||
| Usage | Street Sprinkler | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 8410mm | ||
| Width | 2480mm | ||
| Height | 3500mm | ||
| Curb Weight | 6440kg | ||
| Gross Weight | 18000kg | ||
| Seats | 3 | ||
| Max Speed | 90km/h | ||
| Chassis | |||
| Chassis Model | LZ5180XXYM3ABT | ||
| Front/Rear Overhang | 1340/2370mm | ||
| Number of Leaf Springs | 8/9+5,11/12+9,3/4+3,2/2+1,3/3+2,2/9+5 | ||
| Number of Axles | 2 | ||
| Wheelbase | 4700,5100,5700,6300,4500mm | ||
| Axle Load | 6500/11500kg | ||
| Front Wheel Track | 1916,1940mm | ||
| Rear Wheel Track | 1800mm | ||
| Approaching/Departuring Angle | 20/10° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 10.00-20 18PR,10.00R20 18PR,275/80R22.5 18PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| YC4EG170-50 | Guangxi Yuchai Machinery Co., Ltd. | 125kW | 4730ml |
| YC4EG185-50 | Guangxi Yuchai Machinery Co., Ltd. | 136kW | 4730ml |
| ISD160 50 | Dongfeng Cummins Engine Co., Ltd. | 118kW | 4500ml |
| ISD180 50 | Dongfeng Cummins Engine Co., Ltd. | 132kW | 4500ml |
| YC4EG200-50 | Guangxi Yuchai Machinery Co., Ltd. | 147kW | 4730ml |
| ISD200 50 | Dongfeng Cummins Engine Co., Ltd. | 140kW | 4500ml |
| YC4EG220-50 | Guangxi Yuchai Machinery Co., Ltd. | 160kW | 4730ml |
| YCS04180-60 | Guangxi Yuchai Machinery Co., Ltd. | 132kW | 4156ml |
