| Basic Information |
| Usage |
Road Maintenance Vehicle |
| Fuel Type |
Diesel |
| Emission Standard |
GB17691-2005 national Ⅴ emission standards, GB3847-2005 |
| Length |
9130,8860mm |
| Width |
2400mm |
| Height |
3410mm |
| Curb Weight |
9820kg |
| Gross Weight |
12490kg |
| Seats |
3 |
| Max Speed |
98km/h |
| Chassis |
| Chassis Model |
DFH1120B1 |
| Front/Rear Overhang |
1700/2430,1430/2430mm |
| Number of Leaf Springs |
11/11+10,10/11+10 |
| Number of Axles |
2 |
| Wheelbase |
4700,5000,3800,5600mm |
| Axle Load |
4440/8050kg |
| Front Wheel Track |
1815,1855,1905mm |
| Rear Wheel Track |
1800mm |
| Approaching/Departuring Angle |
13/10,20/10° |
| Tire |
| Number of Tires |
6 |
| Tire |
8.25R20 14PR,8.25R20 16PR,9.00R20 14PR,9.00R20 16PR,10R22.5 14PR,10R22.5 16PR,255/70R22.5,275/70R22.5,275/80R22.5 16PR,9.00-20 14PR,9.00-20 16PR |
| Engine |
| Model |
EQH160-52,EQH180-52,EQH160-53,EQH180-53,ISB180 50,ISB210 50 |
| Brand |
Dongfeng Commercial Vehicle Co., Ltd.; Dongfeng Commercial Vehicle Co., Ltd.; Dongfeng Commercial Vehicle Co., Ltd.; Dongfeng Commercial Vehicle Co., Ltd.; Dongfeng Cummins Engine Co., Ltd.; Dongfeng Cummins Engine Co., Ltd. |
