| Basic Information | |||
| Usage | Refuse Collector | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 5880mm | ||
| Width | 2000mm | ||
| Height | 2310mm | ||
| Curb Weight | 2650kg | ||
| Gross Weight | 4210kg | ||
| Seats | 2 | ||
| Max Speed | 110km/h | ||
| Chassis | |||
| Chassis Model | CNJ1040EDF28V | ||
| Front/Rear Overhang | 1180/1850mm | ||
| Number of Leaf Springs | 3/5+3 | ||
| Number of Axles | 2 | ||
| Wheelbase | 2850mm | ||
| Axle Load | 1590/2620kg | ||
| Front Wheel Track | 1470,1520mm | ||
| Rear Wheel Track | 1470mm | ||
| Approaching/Departuring Angle | 19/12° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 6.50-16 8PR,6.50R16 8PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| 4A2-88C50 | Anhui Quanchai Power Co., Ltd. | 65kW | 2270ml |
