| Basic Information | |||
| Usage | Aluminum Alloy Oil Tanker | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2018 national Ⅵ emission standards | ||
| Length | 7810mm | ||
| Width | 2500mm | ||
| Height | 3100mm | ||
| Curb Weight | 11900kg | ||
| Gross Weight | 18000kg | ||
| Seats | 2,3 | ||
| Max Speed | 101km/h | ||
| Chassis | |||
| Chassis Model | ZZ1187K501GF1 | ||
| Front/Rear Overhang | 1430/1880mm | ||
| Number of Leaf Springs | 11/9+8,3/9+8,3/3+2,2/3+2,3/-,2/-,2/3 | ||
| Number of Axles | 2 | ||
| Wheelbase | 3800,4200,4500,4700,5000mm | ||
| Axle Load | 6500/11500kg | ||
| Front Wheel Track | 1950,2035mm | ||
| Rear Wheel Track | 1848,1860mm | ||
| Approaching/Departuring Angle | 19/20° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 295/80R22.5,12R22.5,11.00R20,10.00R20,275/80R22.5,11R22.5 | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| MC07.27-60 | China National Heavy Duty Group Co., Ltd. | 202kW | 6870ml |
| WP6H245E61 | Weichai Power Co., Ltd. | 180kW | 6220ml |
| WP4.6NQ220E61 | Weichai Power Co., Ltd. | 162kW | 4580ml |
| MC05H.20-60 | China National Heavy Duty Group Co., Ltd. | 147kW | 4910ml |
| MC05H.23-60 | China National Heavy Duty Group Co., Ltd. | 166kW | 4910ml |
| MC05H.25-60 | China National Heavy Duty Group Co., Ltd. | 180kW | 4910ml |
| MC07.25-60 | China National Heavy Duty Group Co., Ltd. | 188kW | 6870ml |
| MC07.29-60 | China National Heavy Duty Group Co., Ltd. | 213kW | 6870ml |
| MC07H.29-60 | China National Heavy Duty Group Co., Ltd. | 213kW | 7360ml |
| WP6H270E61 | Weichai Power Co., Ltd. | 199kW | 6220ml |
