| Basic Information | |||
| Usage | Refuse Collector | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2018 national Ⅵ emission standards | ||
| Length | 6800mm | ||
| Width | 2350mm | ||
| Height | 2980,3100mm | ||
| Curb Weight | 5600kg | ||
| Gross Weight | 11920kg | ||
| Seats | 3 | ||
| Max Speed | 100km/h | ||
| Chassis | |||
| Chassis Model | HFC1121P31K1C6ZS | ||
| Front/Rear Overhang | 1075/1880mm | ||
| Number of Leaf Springs | 9/9+7 | ||
| Number of Axles | 2 | ||
| Wheelbase | 3845mm | ||
| Axle Load | 4120/7800kg | ||
| Front Wheel Track | 1705mm | ||
| Rear Wheel Track | 1785mm | ||
| Approaching/Departuring Angle | 20/15° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 245/70R19.5 14PR,245/70R19.5 16PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| D30TCIF2 | Kunming Yunnei Power Co., Ltd. | 120kW | 2977ml |
