| Basic Information |
| Usage |
Refuse Collector |
| Fuel Type |
Diesel |
| Emission Standard |
GB17691-2005 national Ⅴ emission standards, GB3847-2005 |
| Length |
10572,10702,10752,10802mm |
| Width |
2550mm |
| Height |
3460,3500,3580mm |
| Curb Weight |
15500kg |
| Gross Weight |
31000kg |
| Seats |
2 |
| Max Speed |
88km/h |
| Chassis |
| Chassis Model |
ZZ3316N406ME1 |
| Front/Rear Overhang |
1492/1755,1492/1885,1492/1935,1492/1985mm |
| Number of Leaf Springs |
4/4/5,4/4/10,11/11/10,11/11/12,14/14/12 |
| Number of Axles |
4 |
| Wheelbase |
1950+4025+1350mm |
| Axle Load |
6500/7000/17500(two axles)kg |
| Front Wheel Track |
2022/2022,2041/2041mm |
| Rear Wheel Track |
1830/1830mm |
| Approaching/Departuring Angle |
19/19,19/16° |
| Tire |
| Number of Tires |
12 |
| Tire |
11.00R20,12.00R20 18PR |
| Engine |
| Model |
MC09.38-50,MC11.40-50,MC11.40-52,MC11.44-50,MC11.44-52,MC13.48-50,MC13.54-50 |
| Power |
276,297,297,327,327,356,400kW |
| Brand |
China National Heavy Duty Truck Group Co., Ltd.;China National Heavy Duty Truck Group Co., Ltd.;China National Heavy Duty Truck Group Co., Ltd.;China National Heavy Duty Truck Group Co., Ltd.;China National Heavy Duty Truck Group Co., Ltd.;China National Heavy Duty Truck Group Co., Ltd.;China National Heavy Duty Truck Group Co., Ltd. |
| Displacement |
8765,10518,10518,10518,10518,12419,12419ml |
