| Basic Information |
| Usage |
Refuse Collector |
| Fuel Type |
Diesel |
| Emission Standard |
GB17691-2005 national Ⅴ emission standards, GB3847-2005 |
| Length |
8840mm |
| Width |
2550mm |
| Height |
3450mm |
| Curb Weight |
12500kg |
| Gross Weight |
25000kg |
| Seats |
2 |
| Max Speed |
82km/h |
| Chassis |
| Chassis Model |
ZZ3257N4147E1 |
| Front/Rear Overhang |
1500/1865mm |
| Number of Leaf Springs |
10/12,10/- |
| Number of Axles |
3 |
| Wheelbase |
4125+1350mm |
| Axle Load |
7000/18000(two axles)kg |
| Front Wheel Track |
2022,2041mm |
| Rear Wheel Track |
1830/1830mm |
| Approaching/Departuring Angle |
14/17° |
| Tire |
| Number of Tires |
10 |
| Tire |
295/80R22.5,12.00R20 16PR,11.00R20 |
| Engine |
| Model |
D10.31-50,D10.34-50,D10.38-50,MC09.34-50,MC09.36-50,MC09.38-50,MC11.40-50,MC11.44-50,MC09.40-50 |
| Power |
228,249,276,250,265,276,297,327,294kW |
| Brand |
China National Heavy Duty Truck Group Co., Ltd.;China National Heavy Duty Truck Group Co., Ltd.;China National Heavy Duty Truck Group Co., Ltd.;China National Heavy Duty Truck Group Co., Ltd.;China National Heavy Duty Truck Group Co., Ltd.;China National Heavy Duty Truck Group Co., Ltd.;China National Heavy Duty Truck Group Co., Ltd.;China National Heavy Duty Truck Group Co., Ltd.;China National Heavy Duty Truck Group Co., Ltd. |
| Displacement |
9726,9726,9726,8765,8765,8765,10518,10518,8765ml |
