| Basic Information | |||
| Usage | Refuse Collector | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 8730,8650mm | ||
| Width | 2550,2500mm | ||
| Height | 3650,3500,3300mm | ||
| Curb Weight | 15500kg | ||
| Gross Weight | 31000kg | ||
| Seats | 2 | ||
| Max Speed | 82km/h | ||
| Chassis | |||
| Chassis Model | ZZ3313N2561E1N | ||
| Front/Rear Overhang | 1500/1530,1500/1450mm | ||
| Number of Leaf Springs | 11/11/12 | ||
| Number of Axles | 4 | ||
| Wheelbase | 1800+2550+1350mm | ||
| Axle Load | 6500/7000/17500(two axles)kg | ||
| Front Wheel Track | 2022/2022,2041/2041mm | ||
| Rear Wheel Track | 1860/1860mm | ||
| Approaching/Departuring Angle | 14/31,14/30° | ||
| Tire | |||
| Number of Tires | 12 | ||
| Tire | 11.00R20,12.00R20 18PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| D10.34-50 | China National Heavy Duty Truck Group Co., Ltd. | 249kW | 9726ml |
| D10.38-50 | China National Heavy Duty Truck Group Co., Ltd. | 276kW | 9726ml |
| D10.34-52 | China National Heavy Duty Truck Group Co., Ltd. | 249kW | 9726ml |
| D10.38-52 | China National Heavy Duty Truck Group Co., Ltd. | 276kW | 9726ml |
