| Basic Information | |||
| Usage | Refuse Collector | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 10310,10545,10745,10460,10695,10895mm | ||
| Width | 2500,2550mm | ||
| Height | 3450mm | ||
| Curb Weight | 15200kg | ||
| Gross Weight | 31000kg | ||
| Seats | 2 | ||
| Max Speed | 80km/h | ||
| Chassis | |||
| Chassis Model | ZZ3317N3867E1 | ||
| Front/Rear Overhang | 1500/1860,1500/2095,1500/2295,1500/1895mm | ||
| Number of Leaf Springs | 4/4/-,4/4/12,11/11/-,11/11/12 | ||
| Number of Axles | 4 | ||
| Wheelbase | 1800+3800+1350,1800+4200+1350,1950+3800+1350,1950+4200+1350mm | ||
| Axle Load | 6500/7000/17500(two axles)kg | ||
| Front Wheel Track | 2022/2022,2041/2041mm | ||
| Rear Wheel Track | 1830/1830mm | ||
| Approaching/Departuring Angle | 16/25,16/23,16/21° | ||
| Tire | |||
| Number of Tires | 12 | ||
| Tire | 12.00R20 18PR,11.00R20,12.00-20 18PR,11.00-20 | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| D10.34-50 | China National Heavy Duty Truck Group Co., Ltd. | 249kW | 9726ml |
| D10.38-50 | China National Heavy Duty Truck Group Co., Ltd. | 276kW | 9726ml |
| MC11.40-50 | China National Heavy Duty Truck Group Co., Ltd. | 297kW | 10518ml |
| MC11.44-50 | China National Heavy Duty Truck Group Co., Ltd. | 327kW | 10518ml |
| MC09.38-50 | China National Heavy Duty Truck Group Co., Ltd. | 276kW | 8765ml |
| MC09.40-50 | China National Heavy Duty Truck Group Co., Ltd. | 294kW | 8765ml |
| MC13.48-50 | China National Heavy Duty Truck Group Co., Ltd. | 356kW | 12419ml |
