| Basic Information |
| Usage |
Refuse Collector |
| Fuel Type |
Diesel |
| Emission Standard |
GB17691-2005 national Ⅴ emission standards, GB3847-2005 |
| Length |
8980mm |
| Width |
2496,2550mm |
| Height |
2800,3550mm |
| Curb Weight |
14830kg |
| Gross Weight |
31000kg |
| Seats |
2 |
| Max Speed |
75km/h |
| Chassis |
| Chassis Model |
ZZ3315N2866E1 |
| Front/Rear Overhang |
1550/1480,1550/1455mm |
| Number of Leaf Springs |
4/4/-,4/4/5,4/4/12,11/11/-,11/11/12 |
| Number of Axles |
4 |
| Wheelbase |
1800+2800+1350,1800+2775+1400mm |
| Axle Load |
6500/7000/17500(two axles)kg |
| Front Wheel Track |
2022/2022,2041/2041mm |
| Rear Wheel Track |
1830/1830mm |
| Approaching/Departuring Angle |
20/16° |
| Tire |
| Number of Tires |
12 |
| Tire |
11.00R20,12.00R20 18PR,12R22.5 |
| Engine |
| Model |
D10.31-50,D10.34-50,D10.38-50 |
| Power |
228,249,276kW |
| Brand |
China National Heavy Duty Truck Group Co., Ltd.; China National Heavy Duty Truck Group Co., Ltd.; China National Heavy Duty Truck Group Co., Ltd. |
| Displacement |
9726,9726,9726ml |
