| Basic Information | |||
| Usage | Street Sprinkler | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB3847-2005,GB17691-2018 national Ⅵ emission standards | ||
| Length | 7750mm | ||
| Width | 2520mm | ||
| Height | 3250mm | ||
| Curb Weight | 6500kg | ||
| Gross Weight | 16200kg | ||
| Seats | 3,2 | ||
| Max Speed | 89km/h | ||
| Chassis | |||
| Chassis Model | CA1160P62K1L2A2E6Z | ||
| Front/Rear Overhang | 1400/2350mm | ||
| Number of Leaf Springs | 10/7+6,7/7+6,10/12+8 | ||
| Number of Axles | 2 | ||
| Wheelbase | 4000,4200,5000mm | ||
| Axle Load | 6000/10200kg | ||
| Front Wheel Track | 1800,1827mm | ||
| Rear Wheel Track | 1860,1800mm | ||
| Approaching/Departuring Angle | 16/15° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 9.00R20,10.00R20,10R22.5 | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| CA4DH1-18E6 | China FAW Group Co., Ltd. | 132kW | 3800ml |
| CA4DK1-22E6 | China FAW Group Co., Ltd. | 165kW | 4764ml |
| CA4DK1-18E6 | China FAW Group Co., Ltd. | 139kW | 4764ml |
| CA6DH1-22E6 | China FAW Group Co., Ltd. | 165kW | 5700ml |
