| Basic Information | |||
| Usage | Fire Extinguishing Truck | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2018 national Ⅵ emission standards | ||
| Length | 10900mm | ||
| Width | 2540mm | ||
| Height | 3850mm | ||
| Curb Weight | 26450kg | ||
| Gross Weight | 33800kg | ||
| Seats | 2 | ||
| Max Speed | 85km/h | ||
| Chassis | |||
| Chassis Model | FM460 64R B | ||
| Front/Rear Overhang | 1520/2960mm | ||
| Number of Leaf Springs | 3/3 | ||
| Number of Axles | 3 | ||
| Wheelbase | 4900+1370mm | ||
| Front Wheel Track | 2109mm | ||
| Rear Wheel Track | 1837/1837mm | ||
| Approaching/Departuring Angle | 16/9° | ||
| Tire | |||
| Number of Tires | 10 | ||
| Tire | 385/65R22.5/315/80R22.5 | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| D13K460 EU6 | Volvo Power System Co., Ltd. | 346kW | 12777ml |
