| Basic Information | |||
| Usage | Refuse Collector | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 8860,9445,9730,9010,9595,9880,8960,9110mm | ||
| Width | 2550mm | ||
| Height | 3450mm | ||
| Curb Weight | 15500kg | ||
| Gross Weight | 31000kg | ||
| Seats | 2 | ||
| Max Speed | 82km/h | ||
| Chassis | |||
| Chassis Model | ZZ3317N3067E1 | ||
| Front/Rear Overhang | 1500/1210,1500/1795,1500/2080,1500/1310mm | ||
| Number of Leaf Springs | 11/11/12,4/4/12,11/11/-,4/4/- | ||
| Number of Axles | 4 | ||
| Wheelbase | 1800+3000+1350,1950+3000+1350mm | ||
| Axle Load | 6500/7000/17500((two axles)kg | ||
| Front Wheel Track | 2022/2022,2041/2041mm | ||
| Rear Wheel Track | 1830/1830mm | ||
| Approaching/Departuring Angle | 14/29,14/26,14/23° | ||
| Tire | |||
| Number of Tires | 12 | ||
| Tire | 12.00R20 18PR,11.00R20,12.00-20 18PR,11.00-20 | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| D10.34-50 | China National Heavy Duty Truck Group Co., Ltd. | 249kW | 9726ml |
| D10.38-50 | China National Heavy Duty Truck Group Co., Ltd. | 276kW | 9726ml |
| MC09.38-50 | China National Heavy Duty Truck Group Co., Ltd. | 276kW | 8765ml |
| MC09.40-50 | China National Heavy Duty Truck Group Co., Ltd. | 294kW | 8765ml |
| MC11.40-50 | China National Heavy Duty Truck Group Co., Ltd. | 297kW | 10518ml |
| MC11.44-50 | China National Heavy Duty Truck Group Co., Ltd. | 327kW | 10518ml |
| MC13.48-50 | China National Heavy Duty Truck Group Co., Ltd. | 356kW | 12419ml |
