| Basic Information | |||
| Usage | Refuse Collector | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 10745,10545mm | ||
| Width | 2500mm | ||
| Height | 3500mm | ||
| Curb Weight | 14770kg | ||
| Gross Weight | 31000kg | ||
| Seats | 2 | ||
| Max Speed | 82km/h | ||
| Chassis | |||
| Chassis Model | ZZ3313N386GE1 | ||
| Front/Rear Overhang | 1500/2295,2095mm | ||
| Number of Leaf Springs | 11/11/10 | ||
| Number of Axles | 4 | ||
| Wheelbase | 1800+3800+1350mm | ||
| Axle Load | 6500/7000/17500(two axles)kg | ||
| Front Wheel Track | 2015/2015,2035/2035mm | ||
| Rear Wheel Track | 1850/1850mm | ||
| Approaching/Departuring Angle | 14/14° | ||
| Tire | |||
| Number of Tires | 12 | ||
| Tire | 11.00R20,12.00R20 18PR,12R22.5,295/80R22.5,315/80R22.5 | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| MC07.34-50 | China National Heavy Duty Truck Group Co., Ltd. | 248kW | 6870ml |
| MC07.35-50 | China National Heavy Duty Truck Group Co., Ltd. | 254kW | 6870ml |
