| Basic Information | |||
| Usage | Refuse Collector | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2018 national Ⅵ emission standards, GB3847-2005 | ||
| Length | 8650,8750mm | ||
| Width | 2500mm | ||
| Height | 3180,3350mm | ||
| Curb Weight | 9900kg | ||
| Gross Weight | 18000kg | ||
| Seats | 2,3 | ||
| Max Speed | 89km/h | ||
| Chassis | |||
| Chassis Model | HFC1181P3K2A45YS | ||
| Front/Rear Overhang | 1400/2750, 1400/2550, 1400/2450, 1400/2170, 1400/2320, 1400/2850, 1400/2650, 1400/2270, 1400/2420mm | ||
| Number of Leaf Springs | 3/9+7,3/4+3,9/9+7 | ||
| Number of Axles | 2 | ||
| Wheelbase | 4500,5300mm | ||
| Axle Load | 6500/11500kg | ||
| Front Wheel Track | 1920mm | ||
| Rear Wheel Track | 1800,1830,1860mm | ||
| Approaching/Departuring Angle | 20/11,20/10,20/9,20/8° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 10.00R20 18PR,11R22.5 18PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| YCS06245-60 | Guangxi Yuchai Machinery Co., Ltd. | 180kW | 6234ml |
| D45TCIF1 | Kunming Yunnei Power Co., Ltd. | 162kW | 4461ml |
