| Basic Information | |||
| Usage | Refuse Collector | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2018 national Ⅵ emission standards | ||
| Length | 10100,10460,10280mm | ||
| Width | 2550mm | ||
| Height | 3300,3555mm | ||
| Curb Weight | 14180kg | ||
| Gross Weight | 25000kg | ||
| Seats | 2,3 | ||
| Max Speed | 89km/h | ||
| Chassis | |||
| Chassis Model | DFV1253GP6DJ | ||
| Front/Rear Overhang | 1440/2960mm | ||
| Number of Leaf Springs | 9/10,8/13,9/13 | ||
| Number of Axles | 3 | ||
| Wheelbase | 4350+1350,4750+1350,5400+1350,5700+1350,5900+1350,3600+1350mm | ||
| Axle Load | 7000/18000(two axles)kg | ||
| Front Wheel Track | 1940,1965,1980,2020mm | ||
| Rear Wheel Track | 1860/1860mm | ||
| Approaching/Departuring Angle | 23/13° | ||
| Tire | |||
| Number of Tires | 10 | ||
| Tire | 11.00-20 16PR,11.00R20 18PR,12R22.5 18PR,295/80R22.5 18PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| D6.7NS6B320 | Dongfeng Cummins Engine Co., Ltd. | 231kW | 6700ml |
| D6.7NS6B260 | Dongfeng Cummins Engine Co., Ltd. | 191kW | 6700ml |
| D6.7NS6B230 | Dongfeng Cummins Engine Co., Ltd. | 169kW | 6700ml |
| B6.2NS6B260 | Dongfeng Cummins Engine Co., Ltd. | 191kW | 6200ml |
| B6.2NS6B230 | Dongfeng Cummins Engine Co., Ltd. | 169kW | 6200ml |
| YCS06270-60 | Guangxi Yuchai Machinery Co., Ltd. | 199kW | 6234ml |
| YCS06245-60 | Guangxi Yuchai Machinery Co., Ltd. | 180kW | 6234ml |
| YCS06245-60A | Guangxi Yuchai Machinery Co., Ltd. | 180kW | 6234ml |
| YCK08300-60 | Guangxi Yuchai Machinery Co., Ltd. | 221kW | 7698ml |
