| Basic Information | |||
| Usage | Refuse Collector | ||
| Fuel Type | Natural gas | ||
| Emission Standard | GB17691-2018 national Ⅵ emission standards | ||
| Length | 9295,9495,9695,9580,9630,9780,9930mm | ||
| Width | 2550mm | ||
| Height | 3450,3800mm | ||
| Curb Weight | 15500kg | ||
| Gross Weight | 31000kg | ||
| Seats | 2 | ||
| Max Speed | 80km/h | ||
| Chassis | |||
| Chassis Model | ZZ3317V386GF1L | ||
| Front/Rear Overhang | 1500/1420,1500/1395,1500/1620,1500/1595,1500/1820,1500/1795,1500/1555,1500/1755,1500/1730,1500/1755,1500/1905,1500/1880mm | ||
| Number of Leaf Springs | 4/4/12,11/11/12,11/11/10,4/4/-,11/11/-,5/5/5,5/5/- | ||
| Number of Axles | 4 | ||
| Wheelbase | 1950+2525+1350,1950+2825+1350,1950+3025+1350,1950+3225+1350,1950+3525+1350,1950+3825+1350,1800+2525+1350,1800+2500+1400,1800+2825+1350,1800+2800+1400,1800+3025+1350,1800+3000+1400,1800+3225+1350,1800+3200+1400,1800+3525+1350,1800+3500+1400,1800+mm | ||
| Axle Load | 6500/7000/17500(two axles)kg | ||
| Front Wheel Track | 2022/2022,2041/2041mm | ||
| Rear Wheel Track | 1860/1860mm | ||
| Approaching/Departuring Angle | 17/21° | ||
| Tire | |||
| Number of Tires | 12 | ||
| Tire | 11.00R20 18PR,12.00R20 18PR,12R22.5 18PR,295/80R22.5 18PR,315/80R22.5 18PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| MT13.40-60 | China National Heavy Duty Truck Group Co., Ltd. | 297kW | 12419ml |
| MT13.44-60 | China National Heavy Duty Truck Group Co., Ltd. | 327kW | 12419ml |
