| Basic Information |
| Usage |
Street Sprinkler |
| Fuel Type |
Diesel |
| Emission Standard |
GB17691-2005 national Ⅴ emission standards, GB3847-2005 |
| Length |
7500,7750,8200,8600mm |
| Width |
2480mm |
| Height |
3220mm |
| Curb Weight |
6100kg |
| Gross Weight |
16000kg |
| Seats |
3 |
| Max Speed |
90km/h |
| Chassis |
| Chassis Model |
CL1160LDJ |
| Front/Rear Overhang |
1250/2550,1450/2350,1250/2450,1450/2250,1250/2550,1450/2350,1250/2300,1450/2100,1250/2450,1450/2250,1250/2250,1450/2050,1250/2250,1450/2050,1250/1750,1450/1550mm |
| Number of Leaf Springs |
8/10+7,8/10+8,9/10+8,9/11+8,11/11+10 |
| Number of Axles |
2 |
| Wheelbase |
3700,3800,3950,4200,4500,4700,5100,5600mm |
| Axle Load |
5600/10400kg |
| Front Wheel Track |
1780,1810,1900mm |
| Rear Wheel Track |
1760,1800,1860mm |
| Approaching/Departuring Angle |
19/13,17/14,19/13,17/14,19/13,17/14,19/14,17/16,19/14,17/15,19/13,17/16,19/13,17/16,19/18,17/19° |
| Tire |
| Number of Tires |
6 |
| Tire |
9.00R20 16PR,10.00-20 16PR,10.00R20 16PR |
| Engine |
| Model |
YCD4P4S-170,YC4S150-50,YC6JA180-50 |
| Power |
125,110,132kW |
| Brand |
Guangxi Yuchai Machinery Co., Ltd.; Guangxi Yuchai Machinery Co., Ltd.; Guangxi Yuchai Machinery Co., Ltd. |
| Displacement |
4580,3767,6870ml |
