| Basic Information | |||
| Usage | Vehicle for Special Work | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2018 national Ⅵ emission standards | ||
| Length | 9155mm | ||
| Width | 2500mm | ||
| Height | 3650mm | ||
| Curb Weight | 12870kg | ||
| Gross Weight | 13000kg | ||
| Seats | 2,3 | ||
| Max Speed | 95km/h | ||
| Chassis | |||
| Chassis Model | WS1180GJB | ||
| Front/Rear Overhang | 1435/2720mm | ||
| Number of Leaf Springs | 8/10+8,9/10+8,3/4+3,2/3+2,3/10+8,2/10+8,3/10+3,7/9+6,8/9+6 | ||
| Number of Axles | 2 | ||
| Wheelbase | 3800,4000,4200,5000mm | ||
| Axle Load | 4300/8700kg | ||
| Front Wheel Track | 1930,1880mm | ||
| Rear Wheel Track | 1850,1765mm | ||
| Approaching/Departuring Angle | 16/11° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 10.00R20 18PR,11R22.5 18PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| WP4.6NQ220E61 | Weichai Power Co., Ltd. | 162kW | 4580ml |
| WP6H245E61 | Weichai Power Co., Ltd. | 180kW | 6200ml |
