Basic Information | |||
Usage | Vehicle for Special Work | ||
Fuel Type | Diesel | ||
Emission Standard | GB17691-2018 national Ⅵ emission standards | ||
Length | 9468mm | ||
Width | 2540mm | ||
Height | 3900mm | ||
Curb Weight | 15870kg | ||
Gross Weight | 16000kg | ||
Seats | 2 | ||
Max Speed | 105km/h | ||
Chassis | |||
Chassis Model | QL1251FTFZY | ||
Front/Rear Overhang | 1370/2078mm | ||
Number of Leaf Springs | 7/10 | ||
Number of Axles | 3 | ||
Wheelbase | 4650+1370,5700+1370,5100+1370mm | ||
Axle Load | 5600/10400(two axles)kg | ||
Front Wheel Track | 2060mm | ||
Rear Wheel Track | 1855/1855mm | ||
Approaching/Departuring Angle | 17/13° | ||
Tire | |||
Number of Tires | 10 | ||
Tire | 295/80R22.5 18PR | ||
Engine | |||
Model | Brand | Power | Displacement |
6HK1-TCG60 | ISUZU (China) Engine Co., Ltd. | 221kW | 7790ml |
