| Basic Information | |||
| Usage | Vehicle for Special Work | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2018 national Ⅵ emission standards | ||
| Length | 12400mm | ||
| Width | 2500mm | ||
| Height | 4000mm | ||
| Curb Weight | 30870kg | ||
| Gross Weight | 31000kg | ||
| Seats | 2,3 | ||
| Max Speed | 110km/h | ||
| Chassis | |||
| Chassis Model | ZZ1317N466GF1 | ||
| Front/Rear Overhang | 1430/2700mm | ||
| Number of Leaf Springs | 11/11/12,11/11/10,3/3/10,3/3/5,3/3/4,2/2/4,3/3/-,2/2/-,3/3/-/-,2/2/-/-,4/4/5,4/4/-/- | ||
| Number of Axles | 4 | ||
| Wheelbase | 1800+3800+1350,1800+3775+1400,1800+4300+1350,1800+4275+1400,1800+4600+1350,1800+4575+1400,1950+3825+1350,1950+3800+1400,1950+4625+1350,1950+4600+1400,1800+3825+1350,1800+3800+1400,1800+4625+1350,1800+4600+1400,1800+3300+1350mm | ||
| Axle Load | 6500/7000/17500(two axles)kg | ||
| Front Wheel Track | 2015/2015,2035/2035mm | ||
| Rear Wheel Track | 1830/1830,1850/1850mm | ||
| Approaching/Departuring Angle | 19/10° | ||
| Tire | |||
| Number of Tires | 12 | ||
| Tire | 315/80R22.5 18PR,295/80R22.5,12R22.5,12.00R20 18PR,11.00R20,315/60R22.5 20PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| MC07.31-60 | China National Heavy Duty Truck Group Co., Ltd. | 228kW | 6870ml |
| MC07.34-60 | China National Heavy Duty Truck Group Co., Ltd. | 251kW | 6870ml |
| WP8.350E61 | Weichai Power Co., Ltd. | 257kW | 7800ml |
| MC09.35-60 | China National Heavy Duty Truck Group Co., Ltd. | 260kW | 8765ml |
| MC09.38-60 | China National Heavy Duty Truck Group Co., Ltd. | 279kW | 8765ml |
| MC09.35B-60 | China National Heavy Duty Truck Group Co., Ltd. | 260kW | 8765ml |
| MC11.44-60 | China National Heavy Duty Truck Group Co., Ltd. | 327kW | 10518ml |
| WP10.5H430E62 | Weichai Power Co., Ltd. | 316kW | 10520ml |
| MC11.40-60 | China National Heavy Duty Truck Group Co., Ltd. | 297kW | 10518ml |
| MC07.33-60 | China National Heavy Duty Truck Group Co., Ltd. | 240kW | 6870ml |
| MC07H.33-60 | China National Heavy Duty Truck Group Co., Ltd. | 240kW | 7360ml |
| MC07H.35-60 | China National Heavy Duty Truck Group Co., Ltd. | 257kW | 7360ml |
| WP9H350E62 | Weichai Power Co., Ltd. | 257kW | 8800ml |
| WP10H400E62 | Weichai Power Co., Ltd. | 294kW | 9500ml |
| MC11.40-61 | China National Heavy Duty Truck Group Co., Ltd. | 297kW | 10518ml |
| MC11.43-61 | China National Heavy Duty Truck Group Co., Ltd. | 319kW | 10518ml |
| MC11.46-61 | China National Heavy Duty Truck Group Co., Ltd. | 341kW | 10518ml |
