| Basic Information | |||
| Usage | Refuse Collector | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 8890,8980,9180mm | ||
| Width | 2550mm | ||
| Height | 2800,3550,3450mm | ||
| Curb Weight | 15500kg | ||
| Gross Weight | 31000kg | ||
| Seats | 2 | ||
| Max Speed | 75km/h | ||
| Chassis | |||
| Chassis Model | ZZ3315N286WE1 | ||
| Front/Rear Overhang | 1550/1390,1550/1480,1550/1680mm | ||
| Number of Leaf Springs | 4/4/-,4/4/5,4/4/12,11/11/-,11/11/12,左14右13/左14右13/12,8/8/10 | ||
| Number of Axles | 4 | ||
| Wheelbase | 1800+2800+1350,1800+2775+1400mm | ||
| Axle Load | 6500/7000/17500(two axles)kg | ||
| Front Wheel Track | 1930/1930,1996/1996,2022/2022,2041/2041mm | ||
| Rear Wheel Track | 1800/1800,1830/1830,1860/1860mm | ||
| Approaching/Departuring Angle | 17/16° | ||
| Tire | |||
| Number of Tires | 12 | ||
| Tire | 11.00R20 18PR,12.00R20 18PR,12R22.5 18PR,315/80R22.5 18PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| MC09.34-50 | China National Heavy Duty Truck Group Co., Ltd. | 250kW | 8765ml |
| MC09.36-50 | China National Heavy Duty Truck Group Co., Ltd. | 265kW | 8765ml |
| MC09.38-50 | China National Heavy Duty Truck Group Co., Ltd. | 276kW | 8765ml |
| MC09.40-50 | China National Heavy Duty Truck Group Co., Ltd. | 294kW | 8765ml |
| WP8.340E51 | Weichai Power Co., Ltd. | 250kW | 7800ml |
| WP10H400E50 | Weichai Power Co., Ltd. | 294kW | 9500ml |
