| Basic Information | |||
| Usage | Refuse Collector | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB3847-2005, GB17691-2018 national Ⅵ emission standards | ||
| Length | 5990,5950mm | ||
| Width | 1980mm | ||
| Height | 2120mm | ||
| Curb Weight | 2720kg | ||
| Gross Weight | 4495kg | ||
| Seats | 2+3 | ||
| Max Speed | 100km/h | ||
| Chassis | |||
| Chassis Model | JX1041TSG26 | ||
| Front/Rear Overhang | 1075/1555,1075/1515mm | ||
| Number of Leaf Springs | 7/4+6,7/5+6 | ||
| Number of Axles | 2 | ||
| Wheelbase | 3360mm | ||
| Axle Load | 1895/2600kg | ||
| Front Wheel Track | 1385mm | ||
| Rear Wheel Track | 1425mm | ||
| Approaching/Departuring Angle | 20/15° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 7.00R16LT 10PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| JX4D30B6H | Jiangling Motors Corporation Ltd. | 85kW | 2892ml |
| JX4D30A6H | Jiangling Motors Corporation Ltd. | 95kW | 2892ml |
