| Basic Information |
| Usage |
Refrigerated Van |
| Fuel Type |
Diesel |
| Emission Standard |
GB17691-2018 national Ⅵ emission standards |
| Length |
5995mm |
| Width |
2060,2160,2260mm |
| Height |
2950,3080,3180,3280mm |
| Curb Weight |
3200kg |
| Gross Weight |
4495kg |
| Seats |
2,3 |
| Max Speed |
95km/h |
| Chassis |
| Chassis Model |
ZZ1047H3315F145Z |
| Front/Rear Overhang |
1160/1555,1180/1535mm |
| Number of Leaf Springs |
3/3+2,8/9+6,3/5+3,2/2+1,2/2+2,3/4+3,2/3+2,1/1+1,11/9+7,11/11+7,3/5+3,3/5+2,3/1+1,3/9+7,3/7+4,3/8+6 |
| Number of Axles |
2 |
| Wheelbase |
3280 mm |
| Front Wheel Track |
1610,1640,1670,1776,1796,1815mm |
| Rear Wheel Track |
1560,1595,1645,1695,1795mm |
| Approaching/Departuring Angle |
18/15° |
| Tire |
| Number of Tires |
6 |
| Tire |
7.00R16LT 10PR |
| Engine |
| Model |
F2.8NS6B156,WP2.3NQ130E61,D25TCIF1,D30TCIF1,WP3NQ160E61,WP3NQ150E61,WP2.5NQ150E61,WP2.5NQ160E61,F2.8NS6B131,F2.5NS6B131,F2.5NS6B150,F2.5NS6B160,WP2.3NQ130E61A |
| Power |
115,96,110,125,118,110,110,118,96,96,110,115,96 kW |
| Brand |
Beijing Foton Cummins Engine Co., Ltd.; Weichai Power Co., Ltd.; Kunming Yunnei Power Co., Ltd.; Kunming Yunnei Power Co., Ltd.; Weichai Power Co., Ltd.; Weichai Power Co., Ltd.; Weichai Power Co., Ltd.; Weichai Power Co., Ltd.; Beijing Foton Cummins Engine Co., Ltd.; Beijing Foton Cummins Engine Co., Ltd.; Beijing Foton Cummins Engine Co., Ltd.; Beijing Foton Cummins Engine Co., Ltd.; Weichai Power Co., Ltd. |
| Displacement |
2780,2289,2499,2977,2970,2970,2490,2490,2780,2498,2498,2498,2289 ml |
