| Basic Information | |||
| Usage | Vehicle for Special Work | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB3847-2005, GB17691-2018 national Ⅵ emission standards | ||
| Length | 5927mm | ||
| Width | 2080mm | ||
| Height | 3054mm | ||
| Curb Weight | 4055kg | ||
| Gross Weight | 4250kg | ||
| Seats | 3 | ||
| Max Speed | 130km/h | ||
| Chassis | |||
| Chassis Model | NJ1046EFC | ||
| Front/Rear Overhang | 1002/1625mm | ||
| Number of Leaf Springs | -/7,-/3,-/1+- | ||
| Number of Axles | 2 | ||
| Wheelbase | 3300mm | ||
| Axle Load | 1500/2750kg | ||
| Front Wheel Track | 1725mm | ||
| Rear Wheel Track | 1538,1750,1558mm | ||
| Approaching/Departuring Angle | 23.5/11° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 195/75R16LT 10PR,195/75R16C 107/105R | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| F1AE8481D | Naveco Ltd. | 95kW | 2287ml |
| F1CE8481K | Naveco Ltd. | 125kW | 2998ml |
