| Basic Information | |||
| Usage | Vehicle for Special Work | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 12480mm | ||
| Width | 2500mm | ||
| Height | 4000mm | ||
| Curb Weight | 30870kg | ||
| Gross Weight | 31000kg | ||
| Seats | 2 | ||
| Max Speed | 90km/h | ||
| Chassis | |||
| Chassis Model | FM420 84R B | ||
| Front/Rear Overhang | 1365/2700mm | ||
| Number of Leaf Springs | 2/2/3/3 | ||
| Number of Axles | 4 | ||
| Wheelbase | 1995+4405+1370mm | ||
| Axle Load | 6500/6500/18000(two axles)kg | ||
| Front Wheel Track | 2035/2035mm | ||
| Rear Wheel Track | 1834/1834mm | ||
| Approaching/Departuring Angle | 14/10° | ||
| Tire | |||
| Number of Tires | 12 | ||
| Tire | 295/80R22.5 | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| D13C420S EUV | Volvo Power Train | 310kW | 12777ml |
