| Basic Information | |||
| Usage | Refuse Collector | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 8555,8505mm | ||
| Width | 2521mm | ||
| Height | 3140mm | ||
| Curb Weight | 11740kg | ||
| Gross Weight | 25000kg | ||
| Seats | 2,3 | ||
| Max Speed | 94km/h | ||
| Chassis | |||
| Chassis Model | CA1250P63K1L3T1E5Z | ||
| Front/Rear Overhang | 1400/1455mm | ||
| Number of Leaf Springs | 11/11,3/11,9/10 | ||
| Number of Axles | 3 | ||
| Wheelbase | 4800+1350,4600+1350,4350+1350,4300+1350mm | ||
| Axle Load | 7000/18000(two axles)kg | ||
| Front Wheel Track | 1950mm | ||
| Rear Wheel Track | 1847/1847,1878/1878mm | ||
| Approaching/Departuring Angle | 19/18° | ||
| Tire | |||
| Number of Tires | 10 | ||
| Tire | 11.00R20,12R22.5 | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| CA6DK1-26E5 | China FAW Group Co., Ltd. | 195kW | 7146ml |
| CA6DK1-26E51 | China FAW Group Co., Ltd. | 195kW | 7146ml |
| CA6DK1-28E51 | China FAW Group Co., Ltd. | 209kW | 7146ml |
| CA6DK1-32E51 | China FAW Group Co., Ltd. | 239kW | 7146ml |
