| Basic Information |
| Usage |
Vehicle for Special Work |
| Fuel Type |
Diesel |
| Emission Standard |
GB17691-2005 national Ⅴ emission standards, GB3847-2005 |
| Length |
9980,8980,8440mm |
| Width |
2500mm |
| Height |
3950,3750mm |
| Curb Weight |
10500kg |
| Gross Weight |
16000kg |
| Seats |
3 |
| Max Speed |
90km/h |
| Chassis |
| Chassis Model |
HFC5161XXYP3K1A47V |
| Front/Rear Overhang |
1400/2340,1400/2580,1400/2880mm |
| Number of Leaf Springs |
3/4+3,3/9+7,9/9+7 |
| Number of Axles |
2 |
| Wheelbase |
4700,5000,5700,5300mm |
| Axle Load |
5600/10400kg |
| Front Wheel Track |
1800,1820,1870,1920,1960mm |
| Rear Wheel Track |
1800,1860mm |
| Approaching/Departuring Angle |
18/17° |
| Tire |
| Number of Tires |
6 |
| Tire |
9.00R20 16PR,10R22.5 16PR |
| Engine |
| Model |
WP4.165E50,YC4EG185-50,WP4.1Q160E50,YC4S160-50,JND412D190-52,YNF40E1,D45TCIE2,D45TCIE1 |
| Power |
121,136,115,118,140,125,147,162kW |
| Brand |
Weichai (Weifang) Medium Diesel Engine Co., Ltd.; Guangxi Yuchai Machinery Co., Ltd.; Weichai Power Yangzhou Diesel Engine Co., Ltd.; Guangxi Yuchai Machinery Co., Ltd.; Anhui Jianghuai Navistar Diesel Engine Co., Ltd.; Kunming Yunnei Power Co., Ltd.; Kunming Yunnei Power Co., Ltd.; Kunming Yunnei Power Co., Ltd. |
| Displacement |
4500,4730,4088,3767,4748,3920,4460,4460ml |
