Hubei Dali DLQ5161XWTXK5 Mobile Stage

Basic Information
Usage	Vehicle for Special Work
Fuel Type	Diesel
Emission Standard	GB17691-2005 national Ⅴ emission standards, GB3847-2005
Length	9980,8980,8650mm
Width	2500,2550mm
Height	3950,3850,3750mm
Curb Weight	10500kg
Gross Weight	15800kg
Seats	3
Max Speed	89km/h
Chassis
Chassis Model	HFC5181XXYP3K2A47V
Front/Rear Overhang	1400/2580,1400/2550,1400/2880mm
Number of Leaf Springs	3/4+3,3/9+7,9/9+7
Number of Axles	2
Wheelbase	4500,4700,5000,5300,5700mm
Axle Load	5700/10100kg
Front Wheel Track	1785,1800,1820,1870,1910,1920,1960mm
Rear Wheel Track	1810,1830,1860mm
Approaching/Departuring Angle	18/13°
Tire
Number of Tires	6
Tire	10.00R20 18PR,11R22.5 18PR
Engine
Model	Brand	Power	Displacement
YC6JA180-50	Guangxi Yuchai Machinery Co., Ltd.	132kW	6870ml
YC6JA200-50	Guangxi Yuchai Machinery Co., Ltd.	147kW	6870ml
YC6JA220-50	Guangxi Yuchai Machinery Co., Ltd.	162kW	6870ml
CA6DLD-22E5	FAW Jiefang Automobile Co., Ltd. Wuxi Diesel Plant	164kW	6600ml
WP6.180E50	Weichai (Weifang) Medium Diesel Engine Co., Ltd.	132kW	6750ml
WP6.200E50	Weichai (Weifang) Medium Diesel Engine Co., Ltd.	147kW	6750ml
CA6DLD-18E5	FAW Jiefang Automobile Co., Ltd. Wuxi Diesel Plant	134kW	6600ml
D45TCIE1	Kunming Yunnei Power Co., Ltd.	162kW	4460ml
WP6.220E50	Weichai (Weifang) Medium Diesel Engine Co., Ltd.	162kW	6750ml
YC6J200-58	Guangxi Yuchai Machinery Co., Ltd.	147kW	6500ml
CA6DLD-24E5	FAW Jiefang Automobile Co., Ltd. Wuxi Diesel Plant	179kW	6600ml
