| Basic Information |
| Usage |
Refrigerated Van |
| Fuel Type |
Diesel |
| Emission Standard |
GB3847-2005, GB17691-2018 national Ⅵ emission standards |
| Length |
5995mm |
| Width |
2490mm |
| Height |
3520mm |
| Curb Weight |
3200kg |
| Gross Weight |
4495kg |
| Seats |
3 |
| Max Speed |
105km/h |
| Chassis |
| Chassis Model |
BJ1048V9JD6-F3 |
| Front/Rear Overhang |
1110/1525mm |
| Number of Leaf Springs |
3/5+2,3/3+2,2/2+1,3/4+2,3/7+6,3/8+6,1/1+1,9/8+6 |
| Number of Axles |
2 |
| Wheelbase |
3360mm |
| Axle Load |
1850/2645kg |
| Front Wheel Track |
1590,1730,1600,1740mm |
| Rear Wheel Track |
1590,1615,1800,1485,1490,1715mm |
| Approaching/Departuring Angle |
20/16° |
| Tire |
| Number of Tires |
6 |
| Tire |
7.00R16LT 8PR,7.50R16LT 6PR,6.50R16LT 12PR,205/75R16LT 10PR,195/85R16LT 10PR,195/85R16LT 8PR |
| Engine |
| Model |
4J28TC6,Q28-130E60,F2.8NS6B131,F2.8NS6B150,F2.8NS6B156,D30TCIF1,Q23-115E60,D25TCIF1,4F25TC,4F25TC3 |
| Power |
88,96,96,110,115,125,85,110,116,96kW |
| Brand |
Beiqi Foton Motor Co., Ltd.; Anhui Quanchai Power Co., Ltd.; Beijing Foton Cummins Engine Co., Ltd.; Beijing Foton Cummins Engine Co., Ltd.; Beijing Foton Cummins Engine Co., Ltd.; Kunming Yunnei Power Co., Ltd.; Anhui Quanchai Power Co., Ltd.; Kunming Yunnei Power Co., Ltd.; Beiqi Foton Motor Co., Ltd.; Beiqi Foton Motor Co., Ltd. |
| Displacement |
2771,2800,2780,2780,2780,2977,2300,2499,2499,2499ml |
