| Basic Information | |||
| Usage | Refuse Collector | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB3847-2005, GB17691-2018 national Ⅵ emission standards | ||
| Length | 5998mm | ||
| Width | 2550mm | ||
| Height | 2500,2650mm | ||
| Curb Weight | 3800kg | ||
| Gross Weight | 4495kg | ||
| Seats | 2,3 | ||
| Max Speed | 89km/h | ||
| Chassis | |||
| Chassis Model | ZZ1048G17FB5 | ||
| Front/Rear Overhang | 1175/1543,1175/1173mm | ||
| Number of Leaf Springs | 3/5+3,8/9+6,11/9+7,9/12+9,11/11+7,9/10+8,3/5+2,3/3+2,3/3+4 | ||
| Number of Axles | 2 | ||
| Wheelbase | 3280,3360,3650mm | ||
| Axle Load | 1785/2710kg | ||
| Front Wheel Track | 1605,1625,1795,1825,1548mm | ||
| Rear Wheel Track | 1595,1615,1695,1790,1551mm | ||
| Approaching/Departuring Angle | 20/16° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 7.00R16LT 8PR,7.50R16LT 6PR,8.25R16LT 6PR,6.50R16LT 8PR,6.50R16LT 10PR,6.50R16LT 12PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| D30TCIF1 | Kunming Yunnei Power Co., Ltd. | 125kW | 2977ml |
| WP2.3NQ130E61 | Weichai Power Co., Ltd. | 96kW | 2289ml |
| WP3NQ160E61 | Weichai Power Co., Ltd. | 118kW | 2970ml |
| D25TCIF1 | Kunming Yunnei Power Co., Ltd. | 110kW | 2499ml |
| D30TCIF2 | Kunming Yunnei Power Co., Ltd. | 120kW | 2977ml |
| WP3NQ150E61 | Weichai Power Co., Ltd. | 110kW | 2970ml |
| Q23-132E60 | Anhui Quanchai Power Co., Ltd. | 97kW | 2300ml |
| YCDV2561-115 | Guangxi Yuchai Machinery Co., Ltd. | 89kW | 2488ml |
