| Basic Information |
| Usage |
Refuse Collector |
| Fuel Type |
Natural gas |
| Emission Standard |
GB18285-2005, GB11340-2005, GB17691-2005 national Ⅴ emission standards |
| Length |
10238,10438,10638,10763,9638,9838,11538mm |
| Width |
2500,2550mm |
| Height |
3280,3480,3600mm |
| Curb Weight |
15120kg |
| Gross Weight |
31000kg |
| Seats |
2,3 |
| Max Speed |
85km/h |
| Chassis |
| Chassis Model |
CA3310P2K2L4T4NE5A80 |
| Front/Rear Overhang |
1493/1835,1493/2035,1493/1975,1493/2100,1493/1735,1493/1935,1493/2175mm |
| Number of Leaf Springs |
11/11/13,11/11/-,11/11/12 |
| Number of Axles |
4 |
| Wheelbase |
1860+3960+1350,1860+3910+1450,1860+3700+1350,1860+3000+1350,1860+3200+1350,1860+4660+1350mm |
| Axle Load |
6500/6500/18000(two axles)kg |
| Front Wheel Track |
2020/2020,2045/2045mm |
| Rear Wheel Track |
1840/1840,1880/1880mm |
| Approaching/Departuring Angle |
24/39° |
| Tire |
| Number of Tires |
12 |
| Tire |
11.00-20 18PR,11.00R20 16PR,12.00-20 18PR,12.00R20 16PR,12.00R20 18PR |
| Engine |
| Model |
WP12NG350E50,WP12NG380E50,CA6SM2-35E5N,CA6SM2-37E5N,WP10NG336E50,WP10NG336E51,WP12NG380E51,WP13NG430E52,WP12NG400E51,WP12NG350E52,WP12NG400E50 |
| Power |
257,280,261,278,247,247,280,316,294,257,294kW |
| Brand |
Weichai Power West Port (Weifang) New Energy Power Co., Ltd.; Weichai Power West Port (Weifang) New Energy Power Co., Ltd.; China FAW Group Co., Ltd.; China FAW Group Co., Ltd.; Weichai Power West Port (Weifang) New Energy Power Co., Ltd.; Weichai West Port New Energy Power Co., Ltd.; Weichai Power West Port (Weifang) New Energy Power Co., Ltd.; Weichai West Port New Energy Power Co., Ltd.; Weichai Power West Port (Weifang) New Energy Power Co., Ltd.; Weichai West Port New Energy Power Co., Ltd.; Weichai West Port New Energy Power Co., Ltd. |
| Displacement |
11596,11596,11050,11050,9726,9726,11596,12540,11596,11596,11596ml |
