position : Home>>products>>CLW5120XRYE6 Flammable Liquid Transport Van

CLW5120XRYE6 Flammable Liquid Transport Van

CLW5120XRYE6 Flammable Liquid Transport Van
CLW5120XRYE6 Flammable Liquid Transport Van
Views:0
Basic Information
Usage Aluminum Alloy Oil Tanker
Fuel Type Diesel
Emission Standard GB3847-2005,GB17691-2018 national Ⅵ emission standards
Length 7150,7100mm
Width 2450mm
Height 3350,3150mm
Curb Weight 5000kg
Gross Weight 11950kg
Seats 3
Max Speed 80km/h
Chassis
Chassis Model EQ1125SJ8CDCWXP
Front/Rear Overhang 1130/1970,1130/2070,1130/2170mm
Number of Leaf Springs 8/10+7
Number of Axles 2
Wheelbase 3800,3950,4050mm
Axle Load 4360/7590kg
Front Wheel Track 1755mm
Rear Wheel Track 1586,1650,1800mm
Approaching/Departuring Angle 24.5/13,24.5/12,24.5/11°
Tire
Number of Tires 6
Tire 245/70R19.5,8.25R20
Engine
Model Brand Power Displacement
YCS04190-68 Guangxi Yuchai Machinery Co., Ltd. 140kW 4156ml
D25TCIF1 Kunming Yunnei Power Co., Ltd. 110kW 2499ml
D30TCIF1 Kunming Yunnei Power Co., Ltd. 125kW 2977ml
D40TCIF1 Kunming Yunnei Power Co., Ltd. 135kW 4052ml
NV30-C6D Dongfeng Chaoyang Diesel Co., Ltd. 120kW 2968ml
CY4SK261 Dongfeng Chaoyang Diesel Co., Ltd. 125kW 3856ml
CY4SK361 Dongfeng Chaoyang Diesel Co., Ltd. 125kW 3856ml
YCY30165-60 Guangxi Yuchai Machinery Co., Ltd. 121kW 2970ml
